Part type

Premium original quality

Calculated Volume (dm³)

3.204

Comments

DAF

Distance between holes

110 mm

Length

317 mm

Max. operating pressure

10.0 bar

Medium

Brake fluid SAE J 1703

Mounting

4x Ø 9.0 mm

Port thread 1-4

M14 x 1.5 ( K )

Port thread 11

M16 x 1.5

Port thread 31

Flap Exhaust

Port thread 32

Ø 8.0 mm

Product category

Device

Push-rod thread

M12 x 1.0

Stroke

67.0 mm

Technical specification

OE specification

Temperature range

-40°C to +80°C

Size (mm x mm x mm)

324 x 103 x 96

UPC

193133372509

Weight (kg)

2.276

Weight (lb)

5.0177
