| Bolt lengths | 43.0 mm |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 14.44 |
| Calculated Weight (kg) | 0 |
| Connection port / fitting | M22×1.5 / VOSS 232 |
| Connection specification | JED-388-3 |
| Distance between bolts | 120.6 mm |
| GTIN | 04057877001940 |
| Max. operating pressure | 10.0/8.5 bar |
| Output force service brake | 9.0 kN |
| Output force spring brake | 5.5-10 kN |
| Port: working pressure [p emax.] | 11: 10 bar (13 bar), 12: 8.5 bar (11 bar) |
| Port thread 11 | M22 x 1.5 |
| Product category | Device |
|
|
| Push-rod length | 15 mm |
| Push-rod thread | Ball R8 |
| Release pressure | 4.9 bar |
| Return-spring force | 220 N |
| Stroke | 65/65 mm |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Total length | 286.0 mm |
| Type | 24/24 |
| Type of operation | Disc |
| UPC | 193134005314 |
| Weight (kg) | 9.782 |
| Weight (lb) | 21.57 |
