Part type
Premium original quality
Actuation angle
-19° to +19°
Calculated Volume (dm³)
0.57288
Distance between holes
46.4 mm
Length
R 239 mm
Max. operating pressure
11.0 bar
Mounting
2x Ø 8.5 mm
Port thread 1
Quick Connection Ø 6 mm
Port thread 2
Quick Connection Ø 6 mm
Product category
Device
Stroke of lever
±35°
Technical specification
OE specification
Temperature range
-40°C to +80°C
Type
With Lever
Type of operation
Hole-lever Ø 6.5 mm
Version
With one-way valve
Size (mm x mm x mm)
264 x 62 x 35
UPC
193133308058
Weight (kg)
0.227
Weight (lb)
0.50045
